Two Roller Mill Metal Coil Cold Rolling Mill Machine 2 Hi

Ask Lasest Price
Brand Name :	MAZS
Model Number :	MA Φ120 × 160
Certification :	CE,ISO
Price :	USD
Payment Terms :	T/T or 100% at sight LC or 30% deposit and 70% before shipping.
Supply Ability :	20sets per year
Delivery Time :	120-150 working days

Add to Cart

Product Details
Company Profile

Two Roller Mill Metal Coil Cold Rolling Mill Machine 2 Hi

1. Description of goods:

MA Φ120 × 160 Steel cold Rolling mill equipped with hydraulic expansion cylinder Coiler two roller mill

2. Introduction:
The 2-Hi cold rolling mill, one of metal coil cold rolling mill, is made from good quality raw material. At the same time, we are upgrading with the latest technological equipments when producing this cold rolling mill. Due to different numbers of rollers, the metal coil cold rolling mill is divided into 2 Hi, 4 Hi, 6 Hi, and 12 Hi AGC.

3. Features:
1. The 2-Hi cold rolling mill is a kind of portable type.
2. One stand and two frames are made from fabricated steel plates.
3. The number 2 Rolls on this cold rolling mill are made of chilled material.
4. It is equipped with heavy duty reduction gear.
5. The screw down system is manual.
6. We adopt one number C.I. casting flywheels.

4. Technical Parameters of 2-Hi Cold Rolling Mill:

Type	Φ120 × 160	Φ150 × 220	Φ175 × 400	Φ250 × 500	Φ320 × 600	Φ400 × 800	Φ500 × 1000
Input thickness (mm)	≤4	≤4	≤4	≤8	≤10	≤20	≤30
Output thickness (mm)	0.15	≥0.35	≥0.35	≥0.4	≥0.4	≥0.5	≥0.6
Strip (mm)	10-100	≤150	300	370	450	≤600	800
Rolling pressure (T)	65	100	100	120	150	160	260
Rolling speed (m/min)	12	13	13	13	13-15	13-15	15-25
Main motor (KW)	22	30	37	55	75	155	160
Press-down motor (KW)	1.5	2.2	2.2	3	4	4	7.5
Press-down speed (mm/s)	0.09	0.09	0.09	0.09	0.09	0.12	0.12
Speed reducer	JZQ550	JZQ750	JZQ750	JZQ750	JZQ1000	JZQ115	JZQ130
Weight (T)	4.8	5.8	7	12.8	19	40	50
