    Steel coil slitting line used to thickness 0.6~10mm for cold rolling mill, welded pipe mill, roll forming machine, etc

    Ask Lasest Price
    Brand Name : MAZS
    Model Number : MA-(0.6~5)×1500mm
    Certification : CE
    Price : USD
    Payment Terms : 100% at sight LC or 30% deposit and 70% before shipping.
    Supply Ability : 50 sets per year
    Delivery Time : 90 working days
    • Product Details
    • Company Profile

    Steel coil slitting line used to thickness 0.6~10mm for cold rolling mill, welded pipe mill, roll forming machine, etc

    1. Product name:

    Steel coil slitting line used to thickness 0.6~10mm for cold rolling mill, welded pipe mill, roll forming machine, etc​.


    2. Introduction:

    Capacity of middle thick steel coil slitting line is mainly used to slit steel coils of thickness 0.6~5 mm, 1~6 mm, 2-8mm or 3~10mm. And for steel coils with width: 600~1600 mm, 800~1800mm or 800~2000mm into narrower baby coils. This steel slitter is widely used for proving steel strip coils for cold rolling mill, welded pipe mill, roll forming machine, etc.


    3.The detail specification of Steel Slitter as follows:

    • Input coils: HR/CR carbon steel, colored steel, galvanized steel, etc.
    • Steel Slitting Machine Strip thickness: (0.6-5) mm
    • Strip width: 500~1500mm
    • Steel Slitter Inner diameter of coils: Φ508mm, Φ610mm, Φ760mm
    • Max.outer diameter of coils: Φ2000mm
    • Max.coil weight: 30000kg
    • Steel Slitter shaft: Φ250 x 1550mm
    • Material of disc cutter: 6CrW2Si, HRC55-58.
    • Steel Slitting Machine Motor: DC 110KW, with Eurotherm 590 DC speed driver.
    • Recoiling spindle: Φ508×1550mm.
    • Recoiling motor: DC 132KW, with Eurotherm 590 DC speed driver.
    • Steel Slitter speed: (0~80) m/min, adjustable.

    ModelThicknessCoil WeightFinished slitMax Slitting speed
    MA-5 x 15000.6-5mm500-1500mmMax 30TMin. 40mm80m/min
    MA-6 x 16001-6mm600-1600mmMax 30TMin. 50mm70m/min
    MA-8 x 18002-8mm600-1800mmMax 35TMin 50mm80m/min
    MA-10 x 20003-10mm800-2000mmMax 35TMin 60mm60m/min
    Note: The data in the form just as reference according to general ranges, we always design and make each steel slitting machine according to each customer’s specific requirements, so each customer can buy his own well-content line from us.


    5.What service we can get from your company?

    - VIP Service. Due to our standards, we manage to build long-lasting relationships with all our customers.

    We are 24/7 online available for you to answer your questions and solve your problems.


    6. Quality Inspection:

    The machines of our company have many certificates like ISO 9001, CE, SGS, etc.

    Before the shipping, we have a series of quality check system, includes 3 times of inspection for every production procedure. First inspection needs the workers to check and sign on the test report. Second inspection involves department leaders to check and sign on the test report. The Third inspection needs professional inspector to check and ensure the machines are qualified.

    We also give 12 month warranty time to the customer.
