    Thickness 0.3-3mm Steel Coil Slitting Line Machine Galvanized Steel Slitting Equipment

    Ask Lasest Price
    Brand Name : MAZS
    Model Number : MAZS
    Certification : CE
    Price : USD
    Payment Terms : 100% at sight LC or 30% deposit and 70% before shipping.
    Supply Ability : 100sets per year
    Delivery Time : 100 working days
    • Product Details
    • Company Profile

    Thickness 0.3-3mm Steel Coil Slitting Line Machine Galvanized Steel Slitting Equipment

    I. Composition of production line equipment

    1. Hydraulic loading trolley

    2. Hydraulic cantilever decoiler

    3. Coil pressing and uncoiling device

    4. Double roll pinch and plate shearing machine

    5. Electric eye control looper table

    6. Left and right positioning device

    7. Slitting machine

    8. Scrap collecting device (with wire arrangement function)

    9. Electric eye control looper table

    10. Separator device and damping device

    11. Hydraulic recoiler

    12. Unloading trolley

    13. Hydraulic system

    14. Electrical system


    Thin sheet slitting line is suitable for coil strip thickness (0.2~1) mm, (0.3-2) mm, (0.3-3) mm and (0.4-4)mm; while strip width is changeable: 600mm. 1000mm, 1250mm, 1600mm, 1800mm and so on.

    II. Detailed technical data for our think Slitting lines:

    MA-(0.3~3)×1600mm Coil Slitting Machine in Serbia
    Material of coils: HRC, CRC, GI, PPGI, Q195, Q235, Q345...
    Strip thickness: (0.3-3) mm
    Max. Strip width: 1600mm
    coil ID: ≥Φ508mm
    Coil OD: Φ1800mm
    Max. Coil weight: 20000Kgs
    Slitter motor: 75KW DC motor
    Slitter shaft: Ф220 x 1650mm
    Disc knives on slitter shaft: ID220mm x OD330mm x 10mm, 6CrW2Si.
    Separating disc: ID85 x OD210mm x 6mm, 65Mn
    Tensioning provided by strip passing through frictional wool felt wrapping around wooden plates.
    Recoiler block: Ф508 x 1700mm
    Recoiler motor: 90KW DC motor
    Electric control: Eurotherm 590 DC driver cabinet plus control panels.
    Slitting speed: max 100m/min, adjustable.


    III. Specification form of Metal Coil Slitter:

    ModelThicknessCoil WeightFinished slitMax Slitting speed
    MA-1 x 6000.2-1mm100-600mmMax 8TMin. 20mm50m/min
    MA-2 x 13000.3-2mm300-1300mmMax 15TMin. 25mm80m/min
    MA-3 x 16000.3-3mm500-1600mmMax 20TMin 25mm100m/min
    MA-4 x 16000.4-4mm500-1600mmMax 30TMin 30mm80m/min
    Note: The data in the form just as reference according to general ranges, we always design and make each line according to each customer’s specific requirements, so each customer can buy his own well-content line from us.
